200Wp/m2
Peak Power Output
25%
Cell Efficiency
2200 x 3300 mm
Customisable Size Up To
30
Year Performance Warranty
AURE Cladding
AURE Cladding turns the façade into a high-performance energy-generating asset. It is designed to be deployed using industry-standard installation methods, while bespoke sizing, colour and patterns are available to ensure it fits the project’s design intent. Across large façade areas it generates renewable energy on-site, helping to reduce grid reliance and operational energy costs. IP68 water resistance and built-in thermal management support long-term performance.
Cladding Colour Range
Standard Colour
RAL 7040
Window Grey
170 Wp/m2
Estimated peak power output
Colour: Window Grey
Indicative power outputs only. Actual generation will vary depending on colour selection, cell configuration, panel engineering layout, and panel dimensions. Due to monitor and production variations, on-screen colours may differ from the finished product — we recommend viewing a physical sample. Contact Augenium for project-specific output calculations.
Marble
Ral 9006
White Aluminium
160 Wp/m2
Estimated peak power output
Colour: White Aluminium
Indicative power outputs only. Actual generation will vary depending on colour selection, cell configuration, panel engineering layout, and panel dimensions. Due to monitor and production variations, on-screen colours may differ from the finished product — we recommend viewing a physical sample. Contact Augenium for project-specific output calculations.
Granite
Ral 9006
White Aluminium
160 Wp/m2
Estimated peak power output
Colour: White Aluminium
Indicative power outputs only. Actual generation will vary depending on colour selection, cell configuration, panel engineering layout, and panel dimensions. Due to monitor and production variations, on-screen colours may differ from the finished product — we recommend viewing a physical sample. Contact Augenium for project-specific output calculations.
Brick
Ral 9006
White Aluminium
160 Wp/m2
Estimated peak power output
Colour: White Aluminium
Indicative power outputs only. Actual generation will vary depending on colour selection, cell configuration, panel engineering layout, and panel dimensions. Due to monitor and production variations, on-screen colours may differ from the finished product — we recommend viewing a physical sample. Contact Augenium for project-specific output calculations.
Wood
Ral 9006
White Aluminium
160 Wp/m2
Estimated peak power output
Colour: White Aluminium
Indicative power outputs only. Actual generation will vary depending on colour selection, cell configuration, panel engineering layout, and panel dimensions. Due to monitor and production variations, on-screen colours may differ from the finished product — we recommend viewing a physical sample. Contact Augenium for project-specific output calculations.
Select a colour to suit your architectural style. Bespoke colour options available for projects over 1,000 m².
How does it work?
AURE Cladding integrates photovoltaic technology within a precisely engineered architectural glass cladding panel.
Product Features
Monocrystalline Solar Cells
High-efficiency monocrystalline solar cells generate up to 200Wp/m², turning a previously passive façade surface into a clean energy generator. This offsets grid consumption and supports sustainability targets without using extra land or roof space.
Colour and Pattern Range
AURE Cladding comes in a wide range of colours and patterns, so design freedom stays with the architect. The façade generates power without compromising how the building looks.
Framing Compatibility
AURE Cladding is compatible with standard mounting and framing systems, integrating with the façade systems installers already know. For more complex projects, bespoke engineering support tailors the framing to the building, so the design is shaped around the project rather than an off-the-shelf system.
Sizing
The standard AURE Cladding panel is 1750 x 1150 mm, customisable up to 2200 x 3300 mm.
Why AURE Cladding?
Traditional rooftop solar uses only a fraction of the building envelope. AURE Cladding activates previously passive facade areas, such as walls, replacing conventional façade panels with surfaces that generate clean energy. Available in a wide range of colours and patterns, the product can be tailored to meet architects’ design specifications.
| FEATURE | AURE CLADDING |
|---|---|
| Performance | Up to 200 Wp/m² |
| Installation | Standard industry deployment |
| Durability | Thermal Management Junction Box to support long-term reliability |
| Sustainability Ratings | Energy generation helps to support sustainability goals |
| FEATURE | AURE CLADDING |
|---|---|
| Peak Power Output | Up to 200 Wp/m² |
| Cell Efficiency | More than 25% |
| Open Circuit Voltage (Voc) | ~44 V |
| Max System Voltage | 1000V DC |
| Junction Box | Proprietary Thermal Management Junction Box |
| Connector | MC4 compatible |
| FEATURE | AURE CLADDING |
|---|---|
| Weight | 60 Kg |
| Dimensions | Standard size 1750 mm x 1150 mm Can be customised up to 2200 mm x 3300 mm |
| Glass Composition | 6 mm low-iron glass + 0.76 PVB + TOPCon cells + 0.76 PVB + 6 mm glass |
| Cells | TOPCon |
| Colours | Wide range of colours and patterns available |
These metrics are based on a standard product. Due to the bespoke nature of AURE products, the electrical and physical specifications will vary. For accurate specifications for your building, get in touch.
Backed by Science
AURE products go through rigorous independent testing and certification, giving specifiers and owners reassurance about how each product will perform in the building. That evidence is backed by a 12-year product warranty and a 30-year linear power performance warranty.
IEC 61730
International Electrical Safety Testing
IEC 61215: 2023
PV Module Design Qualification and Type Approval
IEC 61215: 2021
PV Module Design Qualification and Type Approval
CE
European Product Rules
Deployment
Designed for versatility, AURE Cladding supports multiple deployment methods, including rain screen, stick curtain wall and unitised façade systems. Its application is adaptable to different construction methods, making it suitable for a range of project types, including both new builds and retrofits.
Stick Curtain Wall
Stick curtain wall systems are assembled on site, with mullions and transoms installed first and infill panels added afterwards. AURE Cladding integrates as one of those infill panels, giving flexibility on complex or irregular façades where components are fitted piece by piece. It is a practical route where the façade is built up in place rather than delivered as finished sections.
Unitised Façade
Unitised façades are built as complete panel units in the factory, then delivered to site and hung onto the building. AURE Cladding can be incorporated into these prefabricated units, bringing tight quality control and fast installation with minimal on-site labour. This suits high-rise and large-scale projects where speed and consistency matter most.
